| Large End DN | Small End DN | L | Weight |
| mm | mm | mm | kg |
| 150 | 100 | 150 | 27 |
| 200 | 100 | 250 | 35 |
| 200 | 150 | 150 | 39 |
| 250 | 150 | 250 | 50 |
| 250 | 200 | 150 | 51 |
| 300 | 150 | 350 | 64 |
| 300 | 200 | 250 | 62 |
| 300 | 250 | 150 | 66 |
| 350 | 200 | 360 | 84 |
| 350 | 250 | 260 | 89 |
| 350 | 300 | 160 | 90 |
| 400 | 200 | 460 | 105 |
| 400 | 250 | 360 | 106 |
| 400 | 300 | 260 | 107 |
| 400 | 350 | 160 | 113 |
| 450 | 250 | 460 | 128 |
| 450 | 300 | 360 | 129 |
| 450 | 350 | 260 | 134 |
| 450 | 400 | 160 | 135 |
| 500 | 250 | 560 | 141 |
| 500 | 300 | 460 | 142 |
| 500 | 350 | 360 | 156 |
| 500 | 400 | 260 | 146 |
| 500 | 450 | 160 | 146 |
| 600 | 300 | 660 | 201 |
| 600 | 350 | 560 | 207 |
| 600 | 400 | 460 | 203 |
| 600 | 450 | 360 | 204 |
| 600 | 500 | 260 | 189 |
