HDPE Pipes

HDPE Pipes

HDPE Pipe, known as HDPE 100 Pipe (High Density Polyethylene Pipe) and HDPE 80 Pipe used in many projects for potable water, such as pressure water, liquid and gas delivery. Since 1955, HDPE pipe with all developed countries began to be used in pressurized water projects and nowadays such as old concrete, asbestos pipes removing infrastructure in all government procurement in many infrastructure projects replaced the old structure with the HDPE pipe. With ample space to keep the intended use of HDPE pipe, advantageously a so because it is of great importance in international projects.

HDPE pipes areas have increased significantly and the first is preferred as drinking water, today in the oil transport, acid in water crossings, dredger in dredging and also play an important role.

On the HDPE Pipes projects also uses a lot of hdpe pipe fittings. HDPE pipe used safely in pressure water, drinking water projects, gas distribution projects, petroleum distribution projects, irrigation projects, industrial waste, fire fighting systems, dredging projects all kinds of liquid and gas transportation. HDPE pipes also provides less at low cost and in less time than flooring. walkable drilling projects can be laid without making an excavation. easy to use, and farmers in the river project. HDPE pipe can be bent and can be bent without the need for extra fittings is flexible. Longer length again produced resources, labor and time savings.


Technical Specification


Properties Value
Properties Recommended Service Temprature -45°C to 55°C
Vicate Softening Temprature 125°C
Decomposition Temprature 360°C
Ultra Violet Stability Excellent
Flow Factor (C Factor in Hazen Williamson Formula) 150
PH factor of Conveyed Fluid 1.0 to 14.0
Melt Flow Factor 0.20 to 1.10gms in 10 min
Reversion Less than 3%
Density 940.0 to 958.0 kg/m3
Impact Strenght Excellent
Resistance to Abrasion Excellent
Life Expectancy More than 50 years

Product Range


Diameter (Outer) 16mm to 500mm
Material Grades PE63/80/100
Pressure Ratings From PN 2.5 to PN 25
Fittings/Specials HDPE Fittings/Saddles Moulded & Fabricated from 20mm to 500mm
PP Compression Fittings (Push Fit) up to 110mm & Ball Valves
Electro fusion fittings for various sizes
Welding Machines Welding machines & tefelon heaters for pipes ranging from 63mm to 500mm
Standard Reference For Pipes IS 4984, IS 14333, IS 14151 (Part-1 & 22), IS 9537, ISO4427, GR/CDS (TEC/DOT), DIN 8075, BS 6437, AS4130, EN 12201, UL94 (FR)
Fittings IS 8008, ISO 4427

Advantages of HDPE Pipes

  • HDPE Pipe have frost resistant.
  • HDPE Pipes long-lived and durable.
  • HDPE Pipe have high resistant to chemical.
  • HDPE Pipe can be install easily thanks to lightweight specialty.
  • HDPE pipe, rivers, lakes and the sea is very convenient to pass.
  • HDPE Pipe is adapt excellent to terrain area thanks to flexibilty specialty.
  • Polyethylene Pipe (HDPE Pipe) is very strong and resistant to against cracks and bumps.
  • HDPE Pipe can be combined in the outdoor channel and the channel during installation.
  • HDPE Pipe with Carbon Black is produced with additives show resistance to ultraviolet rays from the sun.
  • Due to its excellent weldability, hdpe pipe will not break out of their joints under pressure, provides complete sealing.
  • HDPE pipes easly adapt to their fittings to weld each other by electofusion welding method and butt fusion welding method.
  • PE 100 pipes to not keep dirt, because it is resistant to toxic and does not contain micro-organisms, is not considered a drawback in contact with food with the approval of the Ministry of Health.
